Duxbury LED

Imtra Lights

$67.32
SKU:
ILIM70500.
Availability:
Usually ships within 5 business days
Weight:
0.56 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

The Duxbury LED courtesy light is the ideal courtesy and step light for indirect lighting applications. It contains four "hidden" low power SMD LEDs that project their subtle non-glare illumination in a downward direction to effectively illuminate steps and walkways. The flat profile and slightly rounded edges make them ideal for stair risers. The all stainless steel cover is securely installed with screws over the fully sealed and potted LED sub-assembly, resulting in secure mounting and a 100% waterproof installation. They draw minimal power, run cool, and are completely maintenance free.

Features & Benefits:

  • AISI 316 stainless steel bezel
  • Completely sealed & potted LED sub-assembly
  • Miniscule power consumption
  • Simplified surface-mount installation
  • Integrated constant-current driver
  • Up to 50,000 hours life

Selectable Models ILIM70500 ILIM70501 ILIM70510 ILIM70511 ILIM70530 ILIM70531

Product Details

Housing Material: AISI 316 stainless steel
Finish: White Powder Coat
Dimensions (L x W x H): 3.50 x 0.75 x 0.30 in. (89 x 19 x 7.6mm)
LED Engine: 4 x Warm White SMD LEDs (sealed assembly)
LED Color: Warm
Voltage Input: 10-30VDC
Power Consumption: 0.48W @ 12V / 0.96W @ 24V
Luminous Flux: 9 lms
Electric Protections: 200V Spike Protection
Reverse Polarity
Transient Protection
Ingress Protection: IP65
Wire Size: See Chart
Mounting Method: Screw-mount
1 Year manufacturer's warranty
