Portland 2 PowerLED

$125.00 $112.50
(You save $12.50)
Weight:
0.86 LBS
Availability:
Usually ships within 5 business days
Shipping:
Calculated at checkout
Quantity:

Product Description

The Portland 2 PowerLED recessed spot incorporates the latest in high-flux LED technology with a highly efficient matched optical system. The result is a spotlight resembling a traditional halogen based fixture with uniformity of light across the entire lens area, enhancing aesthetic appearance and eye comfort. The housing of the Portland PowerLED is purpose-built and incorporates a highly efficient anodized aluminum heat sink which keeps the circuit board and LED within a temperature range that assures maximum product life.

Features & Benefits:

  • Low profile design for areas with limited ceiling space
  • Built in driver - no complicated wiring
  • No radiated heat
  • Low power consumption
  • Solid-state circuitry (shock/vibration proof)
  • Multi-voltage (12V or 24V systems)
  • Completely sealed LED sub-assembly
  • Corrosion-proof trim ring
  • Choice of LED colors

The Portland bi-color offers a full-brightness white LED (warm white, cool white, or blue) with white light output equivalent to our all-white Portland PowerLED in both style and light output. In addition, there is a low-power secondary color (either red or blue). The white LED is fully-dimmable with the use of our PWM dimmer and a momentary switch. This light is ideally suited for the helm area and nighttime navigation.

Product Details


Trim Ring Diameter: 3.43" (87.1mm)
Cut-out Diameter: 2.50" (64mm)
Recessed Depth: 0.92" (23mm)
Voltage: 10-30VDC
Input Power (Watts): 3.2W
LED Engine: 1 x 3W high flux LEDs
Beam Angle (FWHM): 84°
Correlated Color Temperature (CCT): 2800K
Color Rendering Index (CRI): 83
Lifetime Hrs (70% lm): 50,000 hrs (70% light output)
Electrical Protection: Reverse Polarity, Transient
Dimmer Module: See ILIM80120
Mounting Method: Screw-mount
Wire Size: See Chart
Ingress Protection: IP65
Manufacturer: Imtra
Weight: 0.325 lbs.

Selectable Models ILIM30906, ILIM30907, ILIM30908, ILIM30909

Warranty Information

1 Year manufacturer's warranty on finish parts

5 Year manufacturer's warranty on LED engine
