Camden PowerLED Bi-Color Boat Lights

Camden PowerLED Bi-Color, Stainless Steel, 10-30VDC, Warm White/Red or Warm White/Blue or Cool White/Red or Cool White/Blue, IP65

Part of the Portland family of down lights, Camden is distinguished by a stylishly placed groove feature that runs just inside the edge of the decorative bezel.  This bi-color version offers a full-brightness white LED (warm white or cool white) that will match other Imtra PowerLED spots and fixtures in both style and light output with the addition of a secondary color. The white LED is fully-dimmable with the use of our PWM dimmer and a momentary switch. A three-position switch may be used to toggle between the two different LED colors and full off. This boat light is ideally suited for the helm area and nighttime navigation.

Dimming: For consistent color temperature and full dimming range, use with our PowerLED Dimmer Module, ILIM80110.

Features & Benefits:

• Low profile design for areas with limited ceiling space
• Built in driver - no complicated wiring
• No radiated heat
• Low power consumption
• Solid-state circuitry (shock/vibration proof)
• Multi-voltage (12V or 24V systems)
• Completely sealed LED sub-assembly
• Elegantly appointed low-profile stainless steel bezel
• Choice of LED colors


  Trim Ring Finish	Stainless Steel
  Trim Ring Material	Stainless Steel
  Lens Material	Frosted glass
  Housing Material	E-coat Aluminum
  Trim Ring Diameter	3.43" (87.1mm)
  Cut-out Diameter	2.50" (64mm)
  Recessed Depth	0.92" (23mm)
  Input Voltage	10-30VDC
  Beam Angle (FWHM)	100°
  Power Consumption	4.7W
  Light Output (Lumens)	179 Lumens
  LED Emitting Color(s)	Warm White/Red or Warm White/Blue or Cool White/Red or Cool White/Blue
  Correlated Color Temperature (CCT)	2800K (White)
  Color Rendering Index (CRI)	83
  Lifetime Hours (L70)	50,000 hrs (70% light output)
  Electrical Protections	Reverse Polarity, 200V Spike Protection, Transient Protection
  Safety Standards Compliance	CE-EMC, UL 1598, UL1149, UL 8750, CSA C22.2#250.0
  Dimmer Interface	Pulse Width Modulation
  Dimmer Module	See ILIM80110
  Mounting Method	Screw-mount
  Ingress Protection	IP65
  Manufacturer	Imtra

  Available Models  ILIM30747, ILIM30757, ILIM30767, ILIM30777
