LED Converter

MSRP: $49.00
$44.10
(You save $4.90 )
SKU:
60563
Weight:
0.45 LBS
Shipping:
Calculated at Checkout
LED Converter
Guaranteed Safe Checkout Paypal And All Credit Cards Accepted
The Lightech Electronic LED Converter is a voltage-regulated power supply.  It features resettable short circuit protection, overload regulation and thermal protection.  It features a universal input voltage of 95-265, 50/60 hz and output of 12VDC.

This LED converter allows small DC LED products to be safely used when the only supply voltage available is line voltage AC.



Product Details
Input voltage: 95-265V 50/60hz
Output voltage: 12VDC or 24VDC
Capacity:  60W, 100W, 150W, 240W, 450W
Max Ambient Temp: 122° F (50° C)
Max Housing Temp: 194° F (90° C)
Dimensions (l x w x h): 3.93 x 1.57 x 1.10 in.
Electric protections: Short Circuit, Overload, Thermal
EMC (RFI): FCC Class B/EN 55015, EN 61000
Classifications: CE, UL Class 2 recognized
Install Location: Within 30' of last light fixture
Wire Size: See Chart
Weight: 0.300 lbs.



IL-LED100WDC12V  IL-LED100WDC24V  IL-LED150WDC12V  IL-LED150WDC24V  IL-LED20WDC24V  IL-LED240WDC24V  IL-LED450WDC24V  IL-LED60WDC12V  IL-LED60WDC24V
