RGB LED Strip Tape, 12 & 24VDC

$175.60
SKU:
31316
Weight:
1.50 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

RGB LED Strip Tape, 12V or 24V, 16' Reel, IP66

with 4-Pin Connector (without Controller Kit)

Engineered with high performance flexible circuit boards for heat management and superior color/light distribution, our professional quality full color change (RGB) LED Strip Tape provides a high level of design flexibility.

Fully sealed to IP66 and UV protected, this product will provide years of top performance. With RGB Controller kit (not included), the system offers RGBW color selection and mixing,  color fade, color jump, strobe, flash, and more. 3M self-adhesive tape provides quick and easy mounting. Our 12V and 24V RGB Strip Tape may be cut to size at clearly marked points every 2". One end has a wire lead with 4-Pin Connector for plug & play connection to the controller (ordered seperately). The other end has wire leads that may be spliced to an additional connector.



  • Includes 4-P Connector for quick-connect to Controller
  • Full RGBW color section and mixing (requires Controller Kit)
  • Flash, strobe, 7-color change , 7-color fade, cycling speed & solid color dim functions (requires Controller Kit)
  • Includes 3M high-bond self-adhesive tape
  • Completely watertight to IP66
  • UV resistant formula

SEE THE FOLLOWING AVAILABLE ACCESSORIES:

RGB CONTROLLER

RGB Y CONNECTOR

RGB 4 PIN MALE CONNECTOR

RGB 5M EXTENSION



SPECIFICATIONS :

Housing Finish/material UV Stable Silicone
Cutability 2" (50mm)
Dimensions 0.50" (12.75mm) w x 0.25" (6.5mm) h
Input Voltage 12VDC
Maximum Run (2) 16' lengths (controller in middle)
Power Consumption 2.2W/ft (7.2W/mt)
Output Color RGBW
Luminous Flux 200 lm/ft (600 lm/mt)
Beam Angle 120°
Mounting Method 3M Self Adhesive Tape (alum channel clips available)
Install Location Interior/exterior
Ingress Protection IP66
Certifications & Compliance U.L.
Warranty 1 Year

Available options ILLT-RGB-12V, ILLT-RGB-24V

1 Year manufacturer's warraty
