At 210 lumens, this is one of the brightest tower cluster bulbs available for marine use. It combines 18 surface mount (SMD) LEDs arrayed in 6 planes for 360° visibility. Proprietary PWM constant-current chipset results in high performance across the entire 10-30VDC range. Its 360° visibility makes it ideal for European style wall appliqués, sconces and table lamps which use the miniature screw base E14 bulb, widely used in Europe. (Replaces ILE14-SMW)
Features & Benefits:
- High output SMD LEDs
- Constant-current drive topology
- Over-voltage protection
- No radiated heat
- Thermally efficient design
Product Details
| Fits Socket: | E14 screw base |
| Typical Applications: | Sconces, Appliqués, Tube Lights |
| Dimensions: | 34.8mm x 43mm (not including base) |
| Input Voltage: | 10-30VDC |
| Power (Watts): | 3.0W |
| Current Draw: | 250mA/12V 125mA/24V |
| LED Emitting Color: | Warm White |
| LED Type/Quantity: | 18 x SMD |
| Beam Angle (FWHM): | 120º (five directions) 360º pattern |
| Light Output (Lumens): | 210 lms |
| Warranty: | 2 Years |
2 Year manufacturer's warranty
