Vimar Eikon American Standard Outlets


0.45 LBS
Calculated at Checkout
Adding to cart… The item has been added

Vimar Eikon American Standard Outlets


A GFCI receptacle is different from conventional receptacles. In the event of a ground fault, a GFCI will trip and quickly stop the flow of electricity to prevent serious injury. This duplex outlet with ground fault circuit interrupter (GFCI) and built-in mounting frame is made to integrate with Eikon World (Eikon-Chrome, Eikon Total Look, and Eikon-Evo) cover plates.


Housing Finish/Material White or Grey/Technopolymer
Recessed Depth 1.37 in (35mm)
Dimensions 4.21 x 2.87 in (107mm x 73mm)
Number of Modules 3
Number of Poles 2P + E
Integrate Switch Manual trip/reset button
Input Voltage Rated voltage 125V ~60Hz
Load Rating 15A
Box Compatibility VMV71303, VMV71303.AU, VMV71703
Mounting Method Frame contains 4 mounting hole locations - see box compatibility
Class A
Electrical Protections GFCI Safety Circuit - 6 milliamp trip current
Certifications & Compliance CE, UL943, cUL943, NEC
Manufacturer Vimar
Warranty 3 Yrs



Available Models  VM21296 VM21296.B
