Low Voltage PowerLED Dimmer Module

MSRP: $149.00
$134.10
(You save $14.90 )
SKU:
ILIM80120
Weight:
0.30 LBS
Shipping:
Calculated at Checkout

Imtra’s model ILIM80120 LED Dimmer Module provides dimming for all Imtra PowerLED Downlights and supports several functions including digital PWM output and four modes of analog input including 0-10V Sink, 0-10V Sink/Source, 4-20mA, 10KΩ-100KΩ Potentiometer.



  • Digital PWM output compatible with all Imtra PowerLEDs
    • Analog output: 0-10V Sink, 0-10V Sink/Source, 4-20mA, and 10KΩ-100KΩ Potentiometer
  • Space-saving compact design
  • Easy to identify input/output wire terminals
  • Works with Single or Double Throw Momentary Switches
  • Dipswitches for customized functions

CLICK HERE for the installation/wiring instructions



Housing Material Black flame retardant ABS (UL94V-0)
Dimensions 0.80" (20mm) H x 2.66" (68mm) W x 2.08" (53mm) Depth
Voltage Input 10-40VDC
Capacity 30 PowerLED Units
Base Dimensions 2.66" (68mm) x 2.08" (53mm)
Power Consumption 1W Max
Load Rating 30 PowerLED fixtures (different wattages)
Dimmer Control Interface Single or Double Throw NO Momentary Push-buttons (Multiple, wired in parallel)
Mounting Method Screw Mounting
Ingress Protection IP40
Class III
Certifications & Compliance CE
Manufacturer Imtra
